Place of Origin:
CHINA
Brand Name:
INOVI
Model Number:
INOVI FH150010
Contact Us
| Model No. | Stainless Steel 304 Corrugated Hose |
|---|---|
| Media | LP Gas, Nature Gas |
| Operating Temperature | -40°C~65°C / -40°F~150°F |
| Maximum Pressure | ≤1/2PSI |
| Standard | ANSI Z21.24/CSA6,10, ANSIZ21.75/CSA6.27 |
| Valve Material: | Brass |
| Valve Core Material: | Brass |
| Specification: |
ID Connection 1/4"ID (3/8"OD) 3/8"FIP, 3/8"MIP, 1/2"FIP, 1/2"MIP 3/8"ID (1/2"OD) 3/8"FIP, 3/8"MIP, 1/2"FIP, 1/2"MIP, 3/4"FIP, 3/4"MIP 1/2"ID (5/8"OD) 1/2"FIP, 1/2"MIP, 3/4"FIP, 3/4"MIP 3/4"ID (1"OD) 3/4"FIP, 3/4"MIP, 1"FIP, 1"MIP |
| Size: |
10, 20, 30, 40, 50, 60, 80, 100, 120, 150,200cm or customed |
Stainless Steel 304 Corrugated Hose For Gas
| Detail Specification | |
| Product Name | Corrugated inlet hose |
| Finishing | Black/yellow coated/uncoated |
| Application |
Dryer, boiler, fireplace, space heater, tankless, water heater, oven, BBQ grill |
| Function | LP Gas, Nature Gas |
| Working pressure | 0.05-1.6Mpa |
| Seal test | 1.6±0.05Mpa and 0.05±0.01Mpa, keep 1 min, no leakage |
| Flow rate | ≤8.3L/min |
| Plating | Acid salt spray test ≥ 24 or 48 hours |
| Plating thickness | Chrome ≥ 0.2µm, nickel ≥ 8µm Or per your request |
| Warranty time | 5 years |
| Customized | OEM & ODM are welcomed |
Item Name: Stainless Steel 304 Corrugated Hose
Pressure: PN2.5
Chemical: resistance to corrossion
Environment: friendly
Health: harmless,non-toxic
Certification: GB/T 19001-2000-ISO 9001:2000
Features:
1. Hygienic and non-toxic
2. High Temperature Resistance
3. Anti-corrosion and no furring
4. Thermal Insulation and EnergyConservation
5. Light with high intensity
6. Agreeable Appearance
7. Easy and Reliable Installation
8. Long service life
Products Materials
- outer hose: Stainless Steel 304
- male fitting: brass/zinc
- surface treatment: Black/yellow coated
- nut: Brass/zinc
- washer: EPDM Rubber
- nut size ( screaw thread): 1/4", 3/8", 1/2", 3/4", 1" can be customized as your required.
- outer hose Diameter: Φ13, Φ14, Φ15, Φ17, Φ18
- length: 10-200cm, can be customized as your required.
- Apply: gas connectors
- Delivery time: 7-30 days (Trial orders, we have stock)
